Product Introduction

Q8 is a dual 8-inch linear array designed in two ways, with two dipole arranged 8-inch bass drivers and a 3-inch tweeter compression driver with waveform transformer. The complex horn geometry combined with advanced bass reflection port design provides complete bandwidth functionality and extended output. These high-performance line array modules provide 80 ° horizontal directionality and can be controlled up to 500 Hz. Mechanical and acoustic design can achieve a vertical array of up to 24 speakers, with a vertical deployment angle of 0 ° to 14 ° and a resolution of 1 °. The speaker box is made of marine plywood and has a PCP (polyurea box protection) coating that is anti impact and weather resistant. The front of the speaker box is protected by a hard metal grille, each side panel has a handle, and the rear also provides two additional grooves. Assemble the three point suspension hardware into the speaker housing.

Product Parameters
