XO33.5

Product Introduction

X033.5 is a sound reinforcement system suitable for medium-range segmented sound sources. It is specifically designed for professional system sound reinforcement and those who require high fidelity and sound pressure level but must not be affected. Designed for high-end residences in terms of appearance. The sound column contains six 6.5-inch midrange units that can bring its frequency response up to 87 Hz and one 3-inch tweeter unit with a compressed diaphragm mounted on an improved J-type DOSC waveguide. This arrangement of speaker units is called a segmented sound source. It has made the best optimization for expanding horizontal coverage and is suitable for small and medium-sized performances, banquet halls, meeting rooms, small pubs and other places for sound amplification.

Product parameters

 Rated Power Aes600W

 Peak Power

1800W
 Frequency Response

60 Hz - 20 kHz

 Speaker Unit

LF 6.5"×6+MF 3"×1

Sensitivity

112dB

Max SPL139dB(Peak)
Impedamce
Dispersion140° ×+5/-21° (H×V)
Wiring Mode2×Neutrik NI4
Dimension(W×H×D)144×1301×170(209)mm
Weight

25.85kg


Box size
